Place of Origin | China |
Brand Name | TBC LED |
Certification | FCC, CE, ROHS |
Model Number | P1.25 |
Specifications
Pixel Pitch | 2mm | ||
Pixel Configuration | SMD1515 | ||
Pixel Density | 250000 pixels/m2 | ||
Module Dimensions | 320 x 160mm | ||
Panel Dimensions (mm) | 640mmx1940mmx55mm | ||
Cabinet Resolution | 320 x 960 | ||
Panel Material | Die Cast Aluminum | ||
Weight per Cabinet | 42kg | ||
Digital Processing | 16bit | ||
Colors | 281 trillion | ||
Contrast Ratio | 5,000 : 1 | ||
Ave/Max Power Consumption | 150/480 | ||
Brightness | >1,000 nits | ||
Refresh Rate | >3,840 Hz | ||
Viewing Angle V/H | 120°/ 120° | ||
Servicing | Front | ||
IP Rating (Front/Rear) | IP 31 | ||
Life Span | 100,000 hours |
