High Brightness And Exquisite Process Outdoor LED Billboard For Digital Advertising

High Brightness and Exquisite Process Outdoor LED Billboard for Digital Advertising

Features

1,Brightness is high enough

For outdoor, it is bright enough for people to see the content of the billboard, and it is currently the only large display terminal that can be used outdoors all day.

2,Large area, wide viewing Angle
The area is dozens of square meters to more than hundreds of square meters, several times or even ten times larger than the traditional electronic advertising media, and in terms of viewing Angle, the indoor viewing Angle can be greater than 160 degrees, outdoor viewing Angle can be greater than 120 degrees. This is more advantageous in some applications.

3,Long life

The service life of the LCD module panel is greater than 100,000 hours, because the backlight is generally LED lights, so the life of the backlight is comparable to the life of the LED screen. Even if it is used 24 hours a day, the equivalent life theory is more than 10 years, and the half-life is 50,000 hours, but how long it can actually be used is also closely related to the use of the product environment and maintenance.

4,Easy maintenance

Unlike other types of large screen, LED large screen if a part is not bright, you can directly change a box, and even now some manufacturers do more sophisticated, you can directly change a LED, not because of a part of the reason so that the whole screen can not be used.

5,Exquisite process

With waterproof, high temperature, low temperature and other outdoor harsh environment.

Advantages

Specifications



No.	Parameter	Value
1	Pixel pitch	10mm
2	Brightness	≥6500nit
3	Pixel configuration	SMD3535
4	Gray scale	65536 levels per color
5	Refresh rate	3840HZ
6	Pixel matrix per panel	120x 120
7	Pixel matrix per sq.m	10000
8	Viewing angle (H /V)	140/140 deg.
9	Power consumption (Max /Avg)	950 / 330
10	Protection Level	IP65
11	Input voltage (AC)	110/240
12	Panel size (W x H x D)	960 x960x 120mm
13	Model size (W x H)	320 x160mm
14	Panel material	Cold Steel
15	Panel weight	43Kg
16	Working temperature/Storage temperature	-40℃ to 70℃/-55℃ to 120℃
17	Life time	≥100,000 hours
18	Signal input format (with video processer)	VGA, DVI,RGBHV,PbPr(HDTV),Composite, S-Video, TV









Application



Outdoor LED Display has a wide range of application scenarios, which can be used in advertising, commercial squares, traffic guidance, city signs, sports venues, cultural and performing arts, large-scale events and weather forecasting, etc., to provide people with a variety of functions such as information transmission, publicity and promotion and entertainment experience.
